日本電波株式會社NDK晶振NX3225GA，是一款小體積晶振尺寸3.2x2.5mm四腳貼片晶振，石英晶體諧振器，無源晶振，石英晶振，無鉛環保晶振，頻率范圍：9.800MHz至50.000MHz，工作溫度范圍：-40℃至+150℃。具有超小型，輕薄型，耐振、耐沖擊等優良的耐環境特性，滿足無鉛焊接的高溫回流溫度曲線要求，符合AEC-Q200標準。該貼片晶振特別適用于：汽車電子設備，車載控制器，汽車音影晶振，汽車氛圍燈控制器，汽車充電樁，汽車電子控制板，汽車大燈恒溫器，無線網絡，藍牙模塊，移動通訊設備，數碼電子等應用。汽車氛圍燈控制器專用晶振NX3225GA-26.000M-STD-CRG-1

汽車氛圍燈控制器專用晶振NX3225GA-26.000M-STD-CRG-1

NX3225GA晶振特點：

緊湊的表面安裝晶體單元，適用于汽車應用，汽車電子晶振

緊湊和薄(Typ：3.2×2.5×0.75mm)

即使在極端惡劣的環境條件下也能具有穩定的啟動特性

優異的抗環境性能，如耐熱、振動和抗沖擊性

回流溫度分布（可用于無鉛焊接）

符合AEC-Q200標準

原廠編碼	品牌	型號	頻率	頻率穩定度	包裝/封裝
NX3225GA-26.000M-STD-CRG-2	NDK晶振	NX3225GA	26MHz	±30ppm	4-SMD, No Lead
NX3225GA-26MHZ-TI	NDK晶振	NX3225GA	26MHz	±40ppm	4-SMD, No Lead
NX3225GA-16.000M-STD-CRG-2	NDK晶振	NX3225GA	16MHz	±30ppm	4-SMD, No Lead
NX3225GA-27.000M-STD-CRG-1	NDK晶振	NX3225GA	27MHz	±30ppm	4-SMD, No Lead
NX3225GA-20.000M-STD-CRG-1	NDK晶振	NX3225GA	20MHz	±30ppm	4-SMD, No Lead
NX3225GA-24.576M-STD-CRG-2	NDK晶振	NX3225GA	24.576MHz	±30ppm	4-SMD, No Lead
NX3225GA-26.000M-STD-CRG-1	NDK晶振	NX3225GA	26MHz	±30ppm	4-SMD, No Lead
NX3225GA-14.31818M-STD-CRG-2	NDK晶振	NX3225GA	14.31818MHz	±30ppm	4-SMD, No Lead
NX3225GA-32M-EXS00A-CG02611	NDK晶振	NX3225GA	32MHz	±20ppm	4-SMD, No Lead
NX3225GA-20.000M-STD-CRG-2	NDK晶振	NX3225GA	20MHz	±30ppm	4-SMD, No Lead
NX3225GA-14.7456M-STD-CRG-1	NDK晶振	NX3225GA	14.7456MHz	±30ppm	4-SMD, No Lead
NX3225GA-27M-STD-CRG-2	NDK晶振	NX3225GA	27MHz	±30ppm	4-SMD, No Lead
NX3225GA-20MHZ-STD-CRA-1	NDK晶振	NX3225GA	20MHz	±150ppm	4-SMD, No Lead
NX3225GA-19.2M-STD-CRG-2	NDK晶振	NX3225GA	19.2MHz	±30ppm	4-SMD, No Lead
NX3225GA-16.9344M-STD-CRG-2	NDK晶振	NX3225GA	16.9344MHz	±30ppm	4-SMD, No Lead
NX3225GA-10.000M-STD-CRG-2	NDK晶振	NX3225GA	10MHz	±30ppm	4-SMD, No Lead
NX3225GA-12MHZ- STD-CRG-2	NDK晶振	NX3225GA	12MHz	±30ppm	4-SMD, No Lead
NX3225GA-12.000M-STD-CRA-1	NDK晶振	NX3225GA	12MHz	±150ppm	4-SMD, No Lead
NX3225GA-12.288M-STD-CRG-2	NDK晶振	NX3225GA	12.288MHz	±30ppm	4-SMD, No Lead
NX3225GA-13.56M-STD-CRG-2	耐高溫晶振	NX3225GA	13.56MHz	±30ppm	4-SMD, No Lead
NX3225GA-14.7456M-STD-CRG-2	NDK晶振	NX3225GA	14.7456MHz	±30ppm	4-SMD, No Lead
NX3225GA-27.12M-STD-CRG-2	NDK晶振	NX3225GA	27.12MHz	±30ppm	4-SMD, No Lead
NX3225GA-25.000M-STD-CRG-1	NDK晶振	NX3225GA	25MHz	±30ppm	4-SMD, No Lead
NX3225GA-25.000M-STD-CRG-2	NDK晶振	NX3225GA	25MHz	±30ppm	4-SMD, No Lead
NX3225GA-16.000M-STD-CRG-1	NDK晶振	NX3225GA	16MHz	±30ppm	4-SMD, No Lead
NX3225GA-12MHZ- STD-CRG-1	NDK晶振	NX3225GA	12MHz	±30ppm	4-SMD, No Lead
NX3225GA-14.31818M-STD-CRG-1	NDK晶振	NX3225GA	14.31818MHz	±30ppm	4-SMD, No Lead
NX3225GA-10.000M-STD-CRG-1	NDK晶振	NX3225GA	10MHz	±30ppm	4-SMD, No Lead
NX3225GA-30.000M-STD-CRG-1	NDK晶振	NX3225GA	30MHz	±30ppm	4-SMD, No Lead
NX3225GA-30.000M-STD-CRG-2	NDK晶振	NX3225GA	30MHz	±30ppm	4-SMD, No Lead
