WXB00003GIKD‐PF,ACT32.768K晶體,6G路由器晶振,WX20B無源諧振器，尺寸為2.0*1.2mm,頻率為32.768KHZ，艾西迪晶振，ACT Crystal，ACT無源晶體，英國艾西迪晶振，石英晶體諧振器，音叉晶體，水晶振動子，2012mm無源晶振，SMD晶振，32.768K晶振，無源時鐘晶體，32.768KHZ貼片晶振，時鐘專用晶體，兩腳無源晶體，無源諧振器，ACT貼片晶振，藍牙音響晶振，智能手機應用晶振，無線設備貼片晶振，移動應用無源晶振，網絡設備專用晶振，高質量貼片晶振，高性能晶振。

SMD晶振產品具有高質量高性能的特點，非常適合用于時鐘應用，也可廣泛用于智能手機，藍牙音響，無線設備，網絡產品等領域.WXB00003GIKD‐PF,ACT32.768K晶體,6G路由器晶振,WX20B無源諧振器.WXB00003GIKD‐PF,ACT32.768K晶體,6G路由器晶振,WX20B無源諧振器參數表

Parameters		Specification	Remarks
Frequency	F_nom	32.768kHz	Fundamental
Frequency tolerance	F_tol	±20ppm	At25°C±3°C
Operating temperaturerange	T_use	‐40°C ~+85°C
Storage temperature	T_stg	‐55°C ~+125°C
Temperature coefficient	K	‐0.04ppm/Δ°C²
Turnover temperature	Ti	25°C±5°C
Load capacitance	CL	7pF, 9pF,12.5pF	Otherload capacitances areavailable ‐please contactACT
Equivalent seriesresistance	ESR	80K?max	OtherlowerESR options are available‐pleasecontact ACT
Shunt capacitance	C0	2.0pFmax
Drivelevel	DL	0.1μWtypical	0.5μWmax
Frequency aging	F_age	±3.0ppmmax	At25°C,Firstyear
Insulationresistance	IR	500MΩmin	AtDC100V ±15V
